NON SPARKING TOOLS
Beryllium Copper Tools Manufacturer In India
Non Sparking Tools are the best alternative for non sparking application purposes in explosive potential environments. All its tools are forged after casting to achieve the best quality tools in the market, both in mechanical properties and attractive finishing. We incorporate to our non sparking tools all our knowledge of decades designing and manufacturing hand tool, making the most ergonomic, easy to be used and nicest design for them.
WHAT IS A "NON SPARKING" TOOLS?
“Non-sparking”, “spark reduced”, “spark-resistant” or “spark-proof” tools are names given to tools made of metals such as brass, bronze, Monel metal (copper-nickel alloy), copper-aluminum alloys (aluminum bronze), or copper-beryllium alloys (Beryllium Copper / Beryllium Bronze).
Hand Tools Manufactured of Steel Alloys are Commonly Used. Preferred “non-sparking” metals have less tensile strength than steels usually used to make tools. A lower tensile strength means the metal has less strength or resistance to tearing apart when stretched under test conditions. It also means that these tools are softer, wear down more quickly than ordinary steel tools, and have to be dressed more frequently.
WHAT IS THE MOST IMPORTANT THING TO KNOW ABOUT "NON SPARKING" TOOLS?
Non-sparking tools also generate sparks sometimes referred to as “cold sparks”. These cold sparks have a low heat level and do not ignite carbon disulfide, which has the lowest ignition point of any substance known to man. Therefore while “non-sparking” tools may lower the risk of a spark, they do not eliminate the possibility of sparks. The name “non-sparking” is misleading because these tools are capable of producing a spark: the term “reduced-sparking tools” better describes these tools.
Non-sparking tools provide protection against fires and explosions in environments where there is a concern about sparks igniting flammable solvents, vapors, liquids, dusts or residues.
Copper Beryllium (CuBe) :
Composition : Be – 1.8% – 2%, Ni + Co – 0.2% – 1.2%, Rest – Cu
Hardness : 283 – 365 Brinell
Tensile Strength : 1250 N/mm2
Aluminum Bronze (AlBr)
Composition : Al – 10%-12%, Ni – 4%-6%, Fe + Mn – <5.8%, Rest – Cu
Hardness : 229-291 Brinell
Tensile Strength : 800 N/mm2
PROPERTIES & FEATURES
Non-Sparking:- Appropriate for explosive potential environments.
Non-Magnetic Safety:- Essential for Equipments that require complete non-magnetic safety.
Corrosion Resistant:- Especially suited for applications in corrosive environments like encountered in marine works or fire-fighting applications.
Forged after Casting:- Provides higher mechanical properties and better finishing.
Ergonomic Designs:- The use of bi-material anti-slippery handles, dipping anti-slippery handles, totally ergonomic designs make operations easier, more comfortable and faster.
TABLE OF RISKS OF EXPLOSION AND MAXIMUM TEMPRATURE
|Temperature of Ignition||T1 (450ºC)||T2(300ºC)||T3(200ºC)||T4(135ºC)||T5(100ºC)||T6(85ºC)|
|IIA (Energy of ignition higher than 0.18 mJ)||Acetone||i-amyl acetate||Amyl alcohol||Acetalde-Hyde|
|IIB (Energy of ignition between 0.06 and 0.18 mJ)||Hydrogen Cyanide||1.3-butadine||Dimethylether||Dietleter|
|Coal gas (lighting gas)||Etylene||Hydrogen Sulphide|
|IIC (Energy of ignition minor of 0.06 ml)||Hydrogen||Acetylene||Bisulphide of carbon|
|Gas of water (CO+H2)||Ethyl nitrate|
The tools made of CuBe alloy can be used in all groups (I, IIA, IIB, IIC) in safety way, always respecting the maximum surface temperature allowed, except with acetylene that can create explosive acetylite gases.
The tools made of Al bronze alloy can be used in safety way, always respecting the maximum surface temperature allowed, except for the IIC group (Hydrogen, gas of water, acetylene, bisulphide of carbon, Ethyl nitrate).
DIFFERENCES AND HOW TO MAKE THE CORRECT CHOICE
Copper Beryllium (CuBe)
Hardness : 283-365 Brinell
Magnetism : Non Ferrous substance in the Composition makes it safer when non-magnetic applications are required.
Durability : Much higher due to the higher hardness and tensile strength. Higher efforts can be afforded.
Price : Higher price due to the special raw material used
Risk of Ignition : Alloy can be used in all groups (I, IIA, IIB, IIC).
Aluminium Bronze (AlBr)
Hardness : 229-291 Brinell
Magnetism : Minimum ferrous component makes them not 100% non-magnetic, although its low long magnetism make it proper for non-critical non-magnetic applications.
Durability : Less than CuBe
Price : More economical than CuBe
Risk of Ignition : Alloy can be used in all groups except IIC and has Higher Risk than CuBe
MAIN FIELDS OF APPLICATION
- Oil Companies
- Gas and Oil Pipelines
- Power Stations
- Paint Making
- Plastic Manufacturing
- Pharmaceutical Industry
- Fireworks Industry
- Chemical Industry
- Paper making industries
- Flour silos and mills
- Alcohol processing industries
- Air Forces
- Weapon and Ammunition Fabrication
- Aerospace Industry
- Automobile Industry
