HIGH TEMPERATURE CABLE

ETP COPPER + MICA + HTS YARN

CONDUCTOR (TWISTED) : ETP Copper

(Options of Nickel / Beryllium Copper – as per order)

INSULATION :  Special High Temperature Resistant Glass Yarn is used for flame retardant, heat resistance and insulation. Colour White. Asbestos Free.

Mica tape is generally as intermediate tape for fire resistance purpose. It has excellent fire resistance, Flame retardant & Heat resistance properties.

TEMPERATURE RANGE INSULATION : -32°C to 1000°C is Working Temperature for Long Hours and upto 1050°C for short duration and do not melt up to 1700°C. Yarns are acid and alkali resistant.

ABRASION RESISTANCE : Poor

FLEXIBILITY : Good

High Temperature cable
High Temperature cable

WATER SUBMERSION : Poor

RESISTANCE TO FLAME : Excellent

RESISTANCE TO WATER / HUMIDITY / MOISTURE : Poor

APPLICATIONS : Heat treating industry, furnace surveys and temperature sensors. Industrial applications in Glass, Steel, and Aluminum Plants.

PACKING : Material will be supplied on SPOOL (Plastic / Wooden)

SPECIAL INSTRUCTION / SPECIAL OPTIONS : On special request and instructions, we can do Metal Braiding, Polyimide Braiding, Fiberglass Braiding.

[table][table_head][table_row][table_heading_cell]Cross section (mm²)[/table_heading_cell][table_heading_cell]Composition[/table_heading_cell][table_heading_cell]Nominal diameter (mm)[/table_heading_cell][table_heading_cell]Max. core resistance at 20°C (Ω/Km)[/table_heading_cell][table_heading_cell]Mass approx. (Kg/Km)[/table_heading_cell][/table_row][/table_head][table_body][table_row][table_cell]0,5[/table_cell][table_cell]7 x 0,30[/table_cell][table_cell]2,55[/table_cell][table_cell]180[/table_cell][table_cell]12,5[/table_cell][/table_row][table_row][table_cell]0,75[/table_cell][table_cell]11 x 0,30[/table_cell][table_cell]2,75[/table_cell][table_cell]115[/table_cell][table_cell]14,7[/table_cell][/table_row][table_row][table_cell]1[/table_cell][table_cell]14 x 0,30[/table_cell][table_cell]3,00[/table_cell][table_cell]92[/table_cell][table_cell]19,0[/table_cell][/table_row][table_row][table_cell]1,5[/table_cell][table_cell]21 x 0,30[/table_cell][table_cell]3,40[/table_cell][table_cell]61[/table_cell][table_cell]24,2[/table_cell][/table_row][table_row][table_cell]2,5[/table_cell][table_cell]35 x 0,30[/table_cell][table_cell]4,40[/table_cell][table_cell]40[/table_cell][table_cell]36,2[/table_cell][/table_row][table_row][table_cell]4[/table_cell][table_cell]56 x 0,30[/table_cell][table_cell]4,60[/table_cell][table_cell]25[/table_cell][table_cell]52[/table_cell][/table_row][table_row][table_cell]6[/table_cell][table_cell]84 x 0,30[/table_cell][table_cell]5,10[/table_cell][table_cell]16[/table_cell][table_cell]75[/table_cell][/table_row][table_row][table_cell]10[/table_cell][table_cell]140 x 0,30[/table_cell][table_cell]7,40[/table_cell][table_cell]8,8[/table_cell][table_cell]142[/table_cell][/table_row][table_row][table_cell]16[/table_cell][table_cell]228 x 0,30[/table_cell][table_cell]9,20[/table_cell][table_cell]6[/table_cell][table_cell]223[/table_cell][/table_row][table_row][table_cell]25[/table_cell][table_cell]354 x 0,30[/table_cell][table_cell]10,60[/table_cell][table_cell]3,8[/table_cell][table_cell]333[/table_cell][/table_row][table_row][table_cell]35[/table_cell][table_cell]495 x 0,30[/table_cell][table_cell]12,85[/table_cell][table_cell]2,7[/table_cell][table_cell]444[/table_cell][/table_row][table_row][table_cell]50[/table_cell][table_cell]707 x 0,30[/table_cell][table_cell]14,00[/table_cell][table_cell]1,9[/table_cell][table_cell]635[/table_cell][/table_row][/table_body][/table]
